Description
★ Real-time, active, energy transfer equalization, after the balance, the inter-cell pressure difference ≤ 3mV
★ Support 2S to 24S battery packs.
★ Single cell voltage collection range: 1V ~ 5V, accuracy: ± 3mV.
★ Support all pool types such as : Li-ion, Lipo, Lifepo4, LTO, super capacitors and other batteries.
★ The balance current is set independently in the range of 0.1~1A/2A/5A/10A, independent of the cell voltage difference.
★ Support balanced cascading to apply to more than 24S of battery packs, in theory, can be cascaded indefinitely; for exampel , can 28S , 32S , 36S , 40S …
★ Support Bluetooth communication, equipped with mobile APP, real-time view of battery status.
★ Equilibrium line resistance detection, abnormal contact failure is found in advance.
★ Power supply range: 40V~ 100V.
★ Super self-protection function, any equalization of the equalization line will not burn the equalizer.
★ Support 2S to 24S battery packs.
★ Single cell voltage collection range: 1V ~ 5V, accuracy: ± 3mV.
★ Support all pool types such as : Li-ion, Lipo, Lifepo4, LTO, super capacitors and other batteries.
★ The balance current is set independently in the range of 0.1~1A/2A/5A/10A, independent of the cell voltage difference.
★ Support balanced cascading to apply to more than 24S of battery packs, in theory, can be cascaded indefinitely; for exampel , can 28S , 32S , 36S , 40S …
★ Support Bluetooth communication, equipped with mobile APP, real-time view of battery status.
★ Equilibrium line resistance detection, abnormal contact failure is found in advance.
★ Power supply range: 40V~ 100V.
★ Super self-protection function, any equalization of the equalization line will not burn the equalizer.
★★★★★
☆ Bluetooth link for Phone-JIKONG BMS
Download link-IOS :Search (JIKONG BMS) in the APP STORE
Download link-Andriod :Search (JK BMS) in the Google STORE
