1. Wide input and output voltage range, input and output up to 20 volts, wider range of use, far better than TPS61088
2. It is especially suitable for low voltage boost applications such as 3.7V lithium batteries, and has a wide range of applications
3. High efficiency and high power, the same power performance as the classic chip TPS61088
4. There is real output short-circuit protection, and the output is short-circuited without burning.
5. Constant voltage and constant current function, can realize boost charging, such as 3.7 volt lithium battery boost charging 12 volt battery
Product parameters:
Input voltage: 2.7~20V
Output voltage: 4.5~20V
Input current: max 10A
Output current: max 4A
Output power: Under 4.2V input, the limit is 30W (3.7V lithium battery can rise to 12V 2A)
Switching frequency: 150KHZ
Package list:
Stable Power Module X1
